Increase the versatility of your Pallet Racking with our open wire mesh panels

Simply select the kit that corresponds to the width & depth of your pallet racking bays

Wire decks are perfect for storing irregular sized loads, or smaller boxes & cartons

The versatile alternative to timber & steel pallet racking decking

Especially recommended for environments where fire regulations stipulate against the use of timber decks

Wire mesh combines low weight with high strength

Manufactured from premium-grade, electro-galvanised steel

Electro-galvanised finish protects from corrosion

Suitable for storing irregular sized loads or boxed goods for easy hand-picking access

Brilliantly suited to damp environments

Open wire mesh decking is also recommended for environments with sprinkler systems

Quick & simple installation - simply place over pallet racking beams

Easy to clean & maintain

Open wire design encourages free air flow & prevents the accumulation of dust

Wire mesh decks offer head protection from falling items when working under tunnel bays

Please Note:

When using mesh decks where the pallet level loads are supported by the pallet beams, the capacity per level will be the same as the pallet beam capacity.

Un-palletised loads not placed directly on the pallet beams will be subject to the load capacities shown in the Product Information section above.

Loads must be uniformly distributed across the mesh decks, and supported by a minimum of 3x mesh deck cross bars.

Mesh Decks are not suitable for storing half pallets?.

There are several various types of wire decking, each with their own advantages. They include:

Inside Waterfall Deck

This type leaves pallet rack beams open for order picking and barcodes/labels are easily accessible.

Up-Turned Waterfall Deck

This option is designed with built-in backstop to prevent materials/products from being pushed too far off the pallet rack.

Drop-In/Flat Flush Deck

Flat flush type is best used for hand-stacked loads and order picking, and it fits well inside load beams.

Flared Channel Deck

This type features a waterfall design with a flared channel that is specifically for box and structural beams.

Inverted Channel Deck

This decking is crafted to prevent the collection of dust and remains inside the channel, with an inverted design that fits snug over beams.

Standard U-Channel Deck

This wire deck also features a waterfall design, with the addition of a standard U-channel to fit over common step beams.

Benefits of Layout Design

Visualizing how the storage, shelving or racking solution will look – before you buy.

Testing and changing layouts at design stage to maximize available space.

Determining the right mix of shelving or racking product, depending on your final design.

Having tangible design plans to present to senior managers, chief executives or chief financial officers.

carries a wide selection of powder coat painted and galvanized wire mesh decking for pallet racking. Wire decking is an ideal add-on for anyone looking for split case storage of items that require a shelf. Wire mesh decking provides a solid shelf surface for added protection, while the open wire mesh allows for water from sprinklers the open access needed in the event of a fire. All the wire decks we carry use heavy duty wire weaved into a mesh grid to create a surface for product to sit on. Laid directly over pallet rack beams, wire decking creates a platform that adds an extra layer of safety and support to the pallet rack itself. Since they are simple to install, wire decks are a popular product in warehouse settings.

We are a China based manufacturer specialising in wire mesh decking, anti-collapse and security partitions for pallet racking & warehouses.
